Wenzhou Fenti Machinery Co.,Ltd
A professional manufacturer and packaging solution provider in the post-press packaging industry, with customers covering more than 80 countries and regions around the world.
Add to Cart
| 1.It can position the window film of printing automatically. To get the high exactly position of printed film. |  |
| 2. The film can be embossed(need to customize pattern mold, the model need to added the cost if choose this function) | |
| 3.The film can be punched with round holes or special-shaped holes(Need to customize the mold, the mould need to added the cost if choose this function) | |
| Model | G-880S |
| Max.Paper Size | W860xL720mm |
| Min.Paper Size | 110X110mm |
| Paper Weight | Kraft Paper:150-1200g/㎡ White Cardboard:230-1200g/㎡ Corrugated Paper:≤3mm |
| Max.Film Size | W450xL430mm |
| Min.Film Size | W30xL65mm |
| Max.Film Unwinding Diameter | 450mm |
| Film Thickness | Horizontal knife；CPE/PE:0.06-0.2mmPVC:0.08-0.2mm APET/PET:0.06-0.2mm Roll Type Cutting knife；CPE/PE:0.1-0.3mmPVC:0.1-0.3mm APET/PET:0.08-0.3mm |
| Film Precision | ±1mm |
| Maximum Speed | Paper L≤330mm:30000pcs/h Paper L＞330mm:1000--15000pcs/h |
| Quantity of Servo Motor | 7Sets |
| Quantity of Stepping Motor | 1Sets Driving Parts: Automatic paper receiving 1 set |
| Power | 380/415V 50/60Hz 13KW |
| Overall Dimension | L570xW170xH160cm |
| Wooden case packing (export) | Size:L360xW135xH165cm G.W.:3026kg N.W.:2860kg |
| Machine weight | 2860kg |
Cake box General Box
Double creasing Three creasing (Optional)
Horizontal creasing Horizontal and Vertical creasing(Optional) Tissue box
